Acquisition module for 5 channels

TCK 4 thermocouple acquisition card and shows them directly on the PC screen and acquire them with the same PC or this module can only be used to transform the thermocouple signal into a 0-5 volt signal in a CUSTOMIZABLE scale. It is possible to add acquisition on SD-CARD in the accessories item. Software included in English. Reading up to 1000 degrees.

TcK thermocouple linear temperature conversion board with a 0-5 volt output signal.

Logger with sd card

Interface that allows you to acquire 4 inputs with 0-5 volt analogue and digital signals including a choice of engine rpm signal, vehicle speed signal, duty cycle such as injector capacity, duty overboost, dwell, frequency.

Interface kit that allows you to acquire up to 4 analog 0-5 volt inputs, duty cycle percentage signals, speed or engine revolutions up to 16,000, all signals recordable on sd card with sampling of over 10 readings per second with analysis software program included and the possibility of exporting excel, csv and consequently pdf files to print or save it.
