  • Compact fuel gauge with controller Fuel gauges level and other level liquids
  • Compact fuel gauge with controller Fuel gauges level and other level liquids
Compact fuel gauge with controller Fuel gauges level and other level liquids

Compact fuel gauge with controller

€132.00
Tax included Solitamente 24 ore

Compact digital indicator for fuel level measurement, usable with any type of float, as a controller is included that allows you to linearize it with your float.

Quantity
  Usually shipped in 24 hours
Remember ! You find it on Protoxide Only!

Add to favorites
Total Rating Total Rating:

0 1 2 3 4
0/5 - 0 reviews

View ratings
0 1 2 3 4 0
0 1 2 3 0 0
0 1 2 0 1 0
0 1 0 1 2 0
0 0 1 2 3 0

  Add Review View Reviews View Reviews
Pinterest


SECURE ENCRYPTED PAYMENTS



TRACKING NUMBER FOR ALL ORDERS



MON-FRIDAY SUPPORT 10.00-12.30 15.00-17.30

Video

  • The reading will be shown with values starting from 0% empty tank to 100% full using your float already present on the car or boat or other means.
  • With an additional cost it is possible, when expressly requested, to modify the same instrument to indicate the liters instead of the percentage.
  • Incredibly compact dimensions, in fact it allows installation with recessed hole 45x22 mm , with a depth of 74mm,
  • Internal 3AMP relay that can be activated based on the set point we have set, which will allow you to activate or deactivate any activator upon reaching it together with a red LED on the display that will indicate that you are in reserve .
  • 12 DC power supply.
  • Total accuracy 0.2% very precise and returns a "softened" value to have a more stable reading and less sensitive to the movement of the liquid by the float.
  • Brightness reduction function by pressing a button.
  • The peculiarity of this instrument is that it can be used with any type of float, as Protoxide adds a small circuit that will allow it to be calibrated according to the minimum and maximum level of your float and your tank.
  • ProtoXide that neither the manufacturer of this kit with instrument and controller guarantees its perfect functioning on any type of float, both increasing and decreasing ohmic resistive and its technical department will be at your disposal for information or post-purchase problems.
  • Very useful to check how much fuel is left in the competition tank such as aluminum or plastic ones without worrying about buying the dedicated instrument that must "read" the sensor inside the tank.
Name Value
Supply 12 Volt
Joint compensation Si
Display 4 cifre
Probe cable length Silicone 3 metri
Precision 0.2%
Depth 75mm
Output 0-5 volts Si
Relay output Si
