Programmable Fiat Punto GT Plug and Play engine control unit

• "Plug and Play" Fiat Punto GT control unit allows it to be replaced with the original engine management, as it has the usual attachment comb thanks to a small wiring made by us already included in the price. It is also possible to purchase the wiring to carry out a clean installation and thus have a new wiring, given the numerous problems that the original wiring presents.
• Fully reprogrammable via included English software that works in REAL TIME.
• Among the many functions there are Launch control, and Bang-Bang or Anti-Lag., Nos management, turbo pressure based on the gear engaged and many other incredible functions that other control units do not have.
• Data acquisition integrated into the control unit! and unique functionality that no other control unit has, data acquisition is used in the usual mapping program which allows you to manage data acquisition as needed in an instant and not like other control units which require you to open another program, wait,,, load the file ,,, this is all automatic and instantaneous.
• NO OTHER COMPONENTS TO PURCHASE SEPARATELY! Although the installation of adequate instrumentation is strongly recommended in order to carry out correct mapping.
• Air conditioning management based on speed to obtain greater performance by deactivating it when maximum speed is required!
• This control unit allows you to eliminate DEBIMETER, BAROMETRIC SENSOR and it is possible via a 3-wire connection to also connect our digital dashboard , to be purchased separately.
• Professional self-diagnosis and pressure sensor (Aps) already integrated, up to 4.5 bar absolute!
• This control unit is able to detect, in the event of an error, whether it is an error on the wire or on the UNICA function sensor and uses the usual fault light (injector image) to indicate this in the event of a fault even without a PC connected by flashing the tail light on, even with the car running.
• It is possible to configure the control unit for both the 1st series and the second series motor or even use two idle motors to have apocalyptic Bangs!
• Password mapping protection.
• VERA phased sequential control unit, with the possibility of deciding the injection phase angle in any condition.
• Oscilloscope integrated inside the control unit with diagnostic functions! Unique with this function that allows you to view whether the signals are exiting or entering correctly by showing the correct waveform.
• Possibility of different mappings that can be activated by the driver.
• Fuel management with Ethanol.
• The software is included in the price and runs on all Windows operating systems (11 included) on PCs with a Microsoft operating system
• Also included is the serial connection cable complete with software to be connected to the control unit itself which becomes USB using a USB converter not included.
• Assistance for both mapping and installation are to be considered additional costs that can be purchased here and whoever purchases it must be responsible for the installation and ensure they possess all the technical requirements necessary for mapping

It is possible to order the control unit by choosing from the following starting maps:

We have available all the internal maps suitable for all engines, this is to make you understand that your own fine-tuning will be necessary after the car has started. (precisely for this reason a base map has already been inserted to allow starting and it is possible to provide you with maps for 1.4 or 1.6 with gt 28 etcc in any case all fine-tuned for your configuration)

• PUNTO GT 1.400 with original injectors with TD04 - GT25 turbo
• PUNTO GT 1,600 with 440cc injectors with GT28 oversized throttle
• PUNTO GT 1400 with oversized injectors 330CC with GT25 turbo
• PUNTO GT 1400 with oversized injectors 440CC with GT28 turbo
• PUNTO GT 1400 with 660cc injectors with Turbo GT25
• PUNTO GT 1600 with 660cc injectors with 4 single coils with Turbo GT25-28
