Fiat Punto Panda engine management control unit Fire 1100 - 1200 - 1400 engines programmable with wiring Programmable control

Engine management control unit Fiat Punto Panda Fire 1100 - 1200 - 1400 engines programmable with wiring

€2,562.00

Tax included Solitamente 24 ore

Programmable racing control unit that can be installed on all engines of the Fiat Alfa Lancia group such as Fiat Punto Panda Fire 1100 - 1200 - 1400 8v engines which uses the rpm and cam sensors and the original coils.

Quantity

Last items in stock

Usually shipped within 24 hours

Add to favorites

Total Rating:

0/5 - 0 reviews

View ratings

	0
	0
	0
	0
	0

Add Review

View Reviews

SECURE ENCRYPTED PAYMENTS

TRACKING NUMBER FOR ALL ORDERS

MON-FRIDAY SUPPORT 10.00-12.30 15.00-17.30

Description

Programmable engine control unit that can be installed on Fiat Punto Panda Fire 1100 - 1200 - 1400 8v engines allows it to be replaced or used in tandem if an original motorized throttle is desired, via a Universal motorsport harness supplied which the installer must shorten following our wiring diagram connection and insert the relevant connectors. This allows you to have an installation with a new wiring , (consider that the original wiring nowadays is often ruined and presents 90% of the problems on the car). This wiring is thus a wiring with wires sized correctly based on the use they will have to support, shielded wires for revolutions and phase sensor and dedicated colors for easy identification, even present and reported in the control unit software. We repeat, you will only have to cut the long wires to size and install the terminal connectors not included, click on the ACCESSORIES tab of this product to purchase them
However, you must be careful because this does not mean that the internal mapping created by the ProtoXide technical department is suitable for all engines (prepared or not, oversized injectors or not...) this is to make you understand that your own fine-tuning will be necessary later that the car left. (precisely for this reason, a basic map has already been inserted to allow starting and circulation, but it is strongly recommended to modify it based on your engine configuration. Or in any case there are several already available.
Fully reprogrammable via included software (English language) that works in REAL TIME.
Among the many functions there are Launch control, and Bang-Bang or Anti-Lag.
The installation of adequate instrumentation to be able to carry out mapping such as a broadband carburetor probe is strongly recommended.
The control unit is managed with phased sequential and is already complete with an internal APS sensor capable of reaching 4.5 absolute bar
It is possible to also connect our digital dashboard to this control unit, to be purchased separately, via a 3-wire connection.
Integrated professional self-diagnosis that allows you to independently indicate whether the faults are faults in the sensors or on the wiring, in fact this control unit is able to detect, in the event of an error, whether it is an error on the wire or on the sensor and uses the usual warning light failure (injector image) to indicate this in the event of a failure even without a PC connected by flashing.
The software is included and runs on all Windows operating systems (from XP to Windows 11) on PCs.
The serial cable for connection to the control unit itself is also included, which becomes USB using a USB converter not included.
Assistance for both mapping and installation are to be considered additional costs that can be purchased here and whoever purchases it must be responsible for the installation and ensure they possess all the technical requirements necessary for mapping
This package includes starting files, configuration and control unit connection instructions. The user must then have all the appropriate skills to complete a correct installation.
